RAILROAD TIE BITS


< Previous           Railroad Tie Drill Bits - RAILROAD TIE BITS - CARBIDE TIPPED - DOUBLE FLUTE     Next  >


RAILROAD TIE BIT

The Most Widely Used Railroad Bit Design

Traditionally, railroad ties (sleepers or railroad cross ties) were wooden.  They were made of softwood or hardwood.  Wood railroad ties, cross ties or sleepers are usually treated with preservatives and can last up to 25 years.  Easy to cut and drill, readily available, and economically viable.  However, today, they are becoming more expensive, with other materials becoming available.  Recently, concrete, steel, and plastic composites have successfully entered into the market and are achieving a growing market share.  B & A can provide solutions to your unique railroad drilling needs, our standard railroad tie bits, railroad tie bore bits, or the carbide tipped Razzor  bits, can all be customized to fit the job at hand.


  Designed to Drill Holes in Wood Railroad Cross Ties / Sleeper

The open flute design prevents chip packing and reduces wood burning.

Double Flute and Tip Geometry Design





RAILROAD TIE BITS
CARBIDE TIPPED - DOUBLE FLUTE

PART
NUMBER
SIZE USL OAL WT
LBS
 7/16" Diameter
RR716X9.5 7/16" 6" 9" 0.40
RR716X12 7/16" 8" 12" 0.50
RR716X18 7/16" 14" 18" 0.65
1/2" Diameter
RR816X9.5 1/2" 6" 9" 0.45
RR816X12 1/2" 8" 12" 0.50
RR816X18 1/2" 14" 18" 0.70
9/16" Diameter
RR916X9.5 9/16" 6" 9" 0.50
RR916X12 9/16" 8" 12" 0.55
RR916X18 9/16" 14" 18" 0.80
5/8" Diameter
RR58X9.5 5/8" 6" 9" 0.55
RR58X12 5/8" 8" 12" 0.60
RR58X18 5/8" 14" 18" 0.90
11/16" Diameter
RR1116X9.5 11/16" 6" 9" 0.60
RR1116X12 11/16" 8" 12" 0.65
RR1116X18 11/16" 14" 18" 1.00
3/4" Diameter
RR34X9.5 3/4" 6" 9" 0.66
RR34X12 3/4" 8" 12" 0.75
RR34x18 3/4" 14" 18" 1.10
13/16" Diameter
RR1316X9.5 13/16" 6" 9" 0.70
RR1316X12 13/16" 8" 12" 0.85
RR1316x18 13/16" 14" 18" 1.20
ADDITIONAL SIZES AND LENGTHS AVAILABLE UPON REQUEST




B&A’s carbide-tipped Railroad Tie bits are especially designed for drilling all types of wooden railroad ties, cross-ties, and pressure treated lumber. These Railroad tie bits offers rapid chip evacuation due to special fluting that provides a large chip storage area and prevents clogging.  The high quality carbide tip, available in a "spear point" (70°) design will drill into the hardest of woods.  Simple put our Railroad Tie Bits are designed for drilling railroad ties.

TO ORDER CALL (800) 327-8611







Don't see what you're looking for JUST CALL 800-327-8611 AND ASK.
