SPLINE DRIVE MASONRY PERCUSSION - QUAD CUTTER
CARBIDE TIPPED HAMMER DRILL BITS

< Previous      B & A Manufacturing Company - spline drive Hammer Drill Bit - Carbide Tipped Drill Bits - Percussion Drill Bits - Straight Shank Drill Bits     B & A Manufacturing Company - Spline Drive Hammer Drill Bit - Carbide Tipped Drill Bits - Percussion Drill Bits - Straight Shank Drill Bits     B & A Manufacturing Company - spline drive Hammer Drill Bit - Carbide Tipped Drill Bits - Percussion Drill Bits - Straight Shank Drill Bits Next  >

B & A Manufacturing Company - Spline Drive Hammer Drill Bit - Carbide Tipped Drill Bits - Percussion Drill Bits - Straight Shank Drill Bits

SPLINE DRIVE MASONRY PERCUSSION HAMMER DRILL BITS
QUAD CUTTER - CARBIDE TIPPED

Designed and produced for spline-drive hammeQS, QS Series Spline-Drive bits are held to exacting tolerances to assure perfect fit as well as maximum impact and torque transmission. B&A Spline Drive rotary/percussion bits are the best available and are designed with maximum strength in order to provide maximum life.

hammer drill bits sds max carbide tipped masonry drill bits



PERCUSSION / HAMMER DRILL - SPLINE DRIVE
QS SERIES - MASONRY
PART
NUMBER		 SIZE USL OAL WT
LBS		 PART
NUMBER		 SIZE USL OAL WT
LBS
5/8" Diameter

1" Diameter
 QS11-0625 5/8" 6" 12" 0.95 QS48-1000 1" 42" 48" 5.40
 QS17-0625 5/8" 12" 18" 1.25 1-1/8" Diameter
 QS23-0625 5/8" 18" 23½" 1.60  QS11-1125 1-1/8" 12" 18" 1.60
 QS30-0500 5/8" 24" 30" 2.08  QS17-1125 1-1/8" 18" 23½" 2.35
 QS36-0500 5/8" 30" 36" 2.50 1-1/4" Diameter
 QS48-0500 5/8" 42" 48" 3.33  QS17-1250 1-1/4" 12" 18" 2.50
3/4" Diameter  QS23-1250 1-1/4" 18" 23½" 2.90
 QS11-0750 3/4" 6" 12" 1.10 QS36-1250 1-1/4" 30" 36" 5.00
 QS17-0750 3/4" 12" 18" 1.35 1-3/8" Diameter
 QS23-0750 3/4" 18" 23½" 2.00  QS17-1375 1-3/8" 12" 18" 3.05
 QS30-0500 5/8" 24" 30" 2.60  QS23-1375 1-3/8" 18" 23½" 4.05
 QS36-0500 5/8" 30" 36" 3.13 1-1/2" Diameter
 QS48-0500 5/8" 42" 48" 4.17  QS17-1500 1-1/2" 12" 18" 3.40
7/8" Diameter  QS23-1500 1-1/2" 18" 23½" 4.65
 QS17-0875 7/8" 12" 18" 1.65 QS36-1500 1-1/2" 30" 36" 6.80
 QS23-0875 7/8" 18" 23½" 2.10 QS48-1500 1-1/2" 42" 48" 9.06
1" Diameter 1-3/4" Diameter
 QS11-1000 1" 6" 11" 1.50  QS17-1750 1-3/4" 18" 23½" 4.85
 QS17-1000 1" 12" 18" 2.05 2" Diameter
 QS23-1000 1" 18" 23½" 2.65 QS36-2000 2" 18" 23½" 5.15
QS36-1000 1" 30" 36" 4.10

B & A Manufacturing Company - SDS Max Hammer Drill Bit - Carbide Tipped Drill Bits - Percussion Drill Bits - Straight Shank Drill Bits



Don't see what you're looking for JUST CALL 800-327-8611 AND ASK.
