FIBERGLASS POLE BITS
SOLID / FILLED CORE POLES


< Previous Next  >

  Designed specifically for drilling through solid/foam core utility poles and cross arms made from fiberglass, resin and/or composite materials. Made with full flute and solid body configuration, enabling the lineman to easily drill through the fiberglass/resin/composite pole. The full fluting allows this bit to remove debris from the hole without melting it.

Cross Arm - Solid Core - Fiberglass Pole Bits - Composite Pole Bits



The Fiberglass Pole Bits (solid core) are generally preferred when creating longer or deeper holes in composite materials such as solid core poles, cross arms, supports, and braces.  The amount of composite material debris created when drilling solid core product is greater than that of the hollow core poles and structures, thus greater debris removal is required or more fluting.  Fiberglass Pole Bits - Solid Core (FGS) are not recommended for hollow core poles and structures - bit whipping can occur in the air gap of the hollow core structure.  Possibly distorting the initial hole and hampering hole alignment.  For Hollow Core Composite Structures, poles, braces, cross arms, and supports - B & A recommends the FGH Series.

PART
NUMBER
SIZE USL OAL WT
LBS
PART
NUMBER
SIZE USL OAL WT
LBS
1/2" Diameter

7/8" Diameter

 FGS70908 1/2" 9" 12" 0.50  FGS70914 7/8" 9" 12" 0.85
 FGS71508 1/2" 15" 18" 0.55  FGS71514 7/8" 15" 18" 1.10
 FGS72108 1/2" 21" 24" 0.70  FGS72114 7/8" 21" 24" 1.50
9/16" Diameter

15/16" Diameter

 FGS70909 9/16" 9" 12" 0.55  FGS70915 15/16" 9" 12" 0.90
 FGS71509 9/16" 15" 18" 0.70  FGS71515 15/16" 15" 18" 1.15
 FGS72109 9/16" 21" 24" 1.00  FGS72115 15/16" 21" 24" 1.60
5/8" Diameter

1" Diameter

 FGS70910 5/8" 9" 12" 0.60  FGS70916 1" 9" 12" 0.95
 FGS71510 5/8" 15" 18" 0.75  FGS71516 1" 15" 18" 1.20
 FGS72110 5/8" 21" 24" 1.15  FGS72116 1" 21" 24" 1.70
11/16" Diameter

1-1/16" Diameter

 FGS70911 11/16" 9" 12" 0.65  FGS70917 1-1/16" 9" 12" 1.35
 FGS71511 11/16" 15" 18" 0.80  FGS71517 1-1/16" 15" 18" 1.85
 FGS72111 11/16" 21" 24" 1.30  FGS72117 1-1/16" 21" 24" 2.15
3/4" Diameter

1-1/8" Diameter

 FGS70912 3/4" 9" 12" 0.70  FGS70918 1-1/8" 9" 12" 1.45
 FGS71512 3/4" 15" 18" 0.90  FGS71518 1-1/8" 15" 18" 1.95
 FGS72112 3/4" 21" 24" 1.40  FGS72118 1-1/8" 21" 24" 2.30
13/16" Diameter Diameter

Additional lengths and sizes available upon request.

 FGS70913 13/16" 9" 12" 0.80
 FGS71513 13/16" 15" 18" 1.05
 FGS72113 13/16" 21" 24" 1.45




Don't see what you're looking for JUST CALL 800-327-8611 AND ASK.
